LUBE BODIES

260V HERITAGE LUBE SKID

Email Page
This class 7 lube body chassis has a 1,000-gallon fuel and lube capacity available in a variety of tank combinations. All oil tanks utilize the Sage Oil Vac exclusive pressure and vacuum system. This body includes a slide out used filter receptacle, stowable 17-gallon drain pan and a fluid control panel to monitor fluid levels, bulk vacuum filling and fluid control.

STANDARD Model 260V Heritage Lube Skid

TANKS

  • (1) 60 gallon (227.125 L) vertical tank (20 in diameter) used oil
  • (1) 60 gallon (227.125 L) vertical tank (20 in diameter) fresh oil & fluid
  • *control panels with LED fluid level indicators for both tanks*

POWER

  • Additonal air source required
  • Vacuum generator for vacuum assist

HOSES AND REELS

  • (1) 1 in x 50 ft (2.54 cm x 15.2 m) used oil hose on spring retractable reel
  • (1) 3/4 in x 50 ft (1.905 cm x 15.2 m) fresh oil hose on spring retractable reel
  • (1) Air reel 3/8 in x 50 ft (0.9525 cm x 15.2 m)

SAGE OIL VAC ATTRIBUTES

  • Patented vacuum process to load fresh fluid tanks (Barrel Straws priced separately, specify quantity and length)
  • Patented used Filter Receptacle
  • 10 micron filters on all new oil reels
  • Patented Filter Stinger (priced separately)

HOSE ENDS, METERS, HANDLES

  • Used oil hose – 1 in (2.54 cm) cam and groove fitting
  • Fresh fluid hoses – 1/2 in (1.27 cm) flush face quick disconnects, adaptable to meters

FRAME

  • Skid mounted
  • Table top frame design
  • Forklift-able

DIMENSIONS AND WEIGHTS

  • Width: 40.5 in (1.0287 m)
  • Length: 44.875 in (1.1398 m)
  • Height: 61.6875 in (1.5668 m)
  • Empty weight: 970 lb (439.985 kg)
  • Operating weight:  1,405 lb (637.2973 kg)
