LUBE BODIES

580V HERITAGE LUBE SKID

Email Page
This class 7 lube body chassis has a 1,000-gallon fuel and lube capacity available in a variety of tank combinations. All oil tanks utilize the Sage Oil Vac exclusive pressure and vacuum system. This body includes a slide out used filter receptacle, stowable 17-gallon drain pan and a fluid control panel to monitor fluid levels, bulk vacuum filling and fluid control.

With four product tanks, the 580V heritage skid provides added versatility to any jobsite maintenance task. The heritage skid design features built-in forklift friendly transport and has plenty of capability for large-fleet services.



TANKS

  • (1) 80 gal. (303 L) ASME tank used oil
  • (3) 30 gal. (114 L) ASME tank fresh oil & fluid
  • (1) 30 gal. (114 L) ASME EPOXY tank- fresh coolant/antifreeze

POWER

  • Additional air source required
  • Vacuum generator for vacuum assist

HOSES AND REELS

  • (1) 1 in. x 50 ft. (2.54 cm x 15.2 m) used oil hose on spring retractable reel
  • (3) 3/4 in. x 50 ft. (1.905 cm x 15.2 m) fresh oil hose on spring retractable reel
  • (1) 5/8 in. x 50 ft. (1.5875 cm x 15.2 m) fresh coolant/antifreeze hose on spring retractable reel
  • (1) 3/8 in. x 50 ft. (0.9525 cm x 15.2 m) air hose on spring retractable reel

SAGE OIL VAC ATTRIBUTES

  • Patented vacuum process to load fresh fluid tanks (Barrel Straws priced separately- specify quantity and length)
  • Patented used filter receptacle
  • Patented filter stinger (priced separately)
  • 25 micron filters on all new oil reels
  • Y-strainer on all new coolant reels

HOSE ENDS, METERS, HANDLES

  • Used Oil hose- 1 in. (2.54 cm) cam and groove fitting
  • Fresh fluid hoses- 1/2 in. (1.27 cm) flush face quick disconnects, adaptable to meters (priced separately, specify quantity and type)

FRAME

  • Skid mounted
  • Table top frame design
  • Forklift-able (empty only)

DIMENSIONS AND WEIGHTS

  • Width: 50 in. (1.27 m)
  • Length: 88 in. (2.24 m)
  • Height: 56.31 in. (1.43 m)
  • Empty weight: 1685 lb. (764.33 kg)
  • Normal max operating weight: 2596 lb. (1177.36 kg)
